Description
FR10GG50V16, Mersen, IEC, class GG, non-indicating, 500Vac, 0.41″ diameter, 16A, 120kA@500V, size 10, for protection of cables, motors and LV-networks. Mersen aM and gG fuse-links cover a wide range of physical sizes and ampere ratings for 400, 500, and 690VAC for protection in electrical distribution circuits and various industrial applications. Most ratings are available in size 8×31 and size 10×38 with an optional indicator, and in size 14×51 and 22×58 with an optional striker to activate an auxiliary contact. Size 10×38 is also available with striker. All cylindrical fuse-links have ceramic bodies and silver-plated contacts. Cylindrical fuse-links “gG” are used for the protection of cables, motors and LV-networks. They limit and cut off unacceptable overcurrents and short-circuit currents up to their nominal breaking capacity. Cylindrical fuse-links “gG” also protect electrical equipment and installations against the dynamic effect of high short-currents. Our technology and process was designed to ensure highly reliable technical performance.
The G200750 is a 16A/500VAC class-GG cylindrical HRC Fuse Link with ceramic body, silver-plated copper/ferrule contacts, midget case style and without visual blown fuse indicator. Cylindrical fuse-links “gG” protect electrical equipment and installations against the dynamic effect of high short-currents. They limit and cut off unacceptable over-currents and short-circuit currents up to their nominal breaking capacity. Our technology and process was designed to ensure highly reliable technical performance. Suitable for cable protection and applications where there are no surges to be absorbed.
European style
Small size
Full range protection
Safest and most reliable protection system
120kA Rated breaking capacity AC
1.9W Power dissipation at In
Applications
Safety, Industrial
Manufacturer Part Number FR10GG50V16
Manufacturer Mersen
Family Series Mersen Fuses
Description Fuse
Fuse Type IEC Ferrule Type
Barrel Type: 10mm x 38mm
Current Rating: 16A Continuous
Voltage Rating: 500Vac
Operating Class: gG
Fuse Power Loss: 1.9W (at rated current). Maximum continuous rated current when fitted in a fuse holder is 16A (no de-rating required). See suitable fuse holder linked below.
Manufacturer is Mersen, previously sold under the Ferraz Shawmut brand.
Manufacturers Part Number: FR10GG50V16 or G200750
Manufacturer
MERSEN
Type of fuse
fuse
Kind of fuse
ceramic, cylindrical, industrial
Current rating
16A
Rated voltage
250V DC/500V AC
Fuse characteristics
gG
Fuse size
10x38mm
Breaking capacity
100kA / 250V DC, 120kA / 500V AC
Fuses application
general overloads protection, protection switchgear
Power dissipation
1.9W
Datasheet: Ferrule fuse-links 10×38 gG 400 to 690VAC
