PXF362500G SquareD Circuit Breaker 2500A 600V 3 Poles

PXF362500G SquareD Circuit Breaker 2500A 600V 3 Poles

PXF362500G Square D / Schneider Electric Molded Case Circuit Breakers 2500A, 600V, 100kA@480V, high interrupting capacity, Bolt-On, complete with Micrologic non-interchangeable trip LSIG – Long-Time, Short-Time, Instantaneous and Ground Fault standard trip functions and rating plug, lugs not included, Solid State electronic, molded case circuit breakers

Contact us today for current availability and pricing.

SKU: PXF362500G Categories: , Tag: Brand:

Description

PXF362500G Square D Main Circuit Breaker 2500 Amp, 600V with Ground Fault integrated system. Electronic breaker not thermal magnetic. Amperage is adjustable with alternate rating plugs.
PXF Frame Style, Molded Case Circuit Breaker, 2500 Amp Sensor Size, Electronic Non-interchangeable Trip Unit, LSIG Trip Unit Functions, 2500 Ampere at 40 Degree Celsius, 3 Pole, Interrupting Ratings: 125 Kiloampere @ 240 VAC, 100 Kiloampere @ 480 VAC, 65 Kiloampere @ 600 VAC, with ARP100 Rating Plug Installed Standard, Without Terminals Standard.
Specifications
Manufacturer Square-D
Warranty One Year
Connection Bolt On
Frame Type P
Amperage 2500
Poles 3
Voltage Max 600
Interrupting Capacity Rating 125 Kiloampere @ 240 VAC, 100 Kiloampere @ 480 VAC, 65 Kiloampere @ 600 VAC
Standard Lug Type Without Terminals Standard
100kAIC@480V
Bolt-On
3 Phase
Long Time, Short Time, Instantaneous and Ground Fault Trip Functions
Solid State
High Interrupting Capacity
Non-Interchangeable Trip and Rating Plug
Lugs Not Included
