Description

170M7636 Bussmann Fuse-link, high speed, 1500 A, AC 1000 V, 200 kA, size 4, 105 x 120 x 95 mm, aR, IEC, type K indicator
Fuse system according to IEC 60269 (EF017676) Other
Fuse construction type according to IEC 60269 (EF015865) 4
Type of current (EF000143) AC
Rated voltage AC (EF007682) 1000 V
Rated current (EF000227) 1500 A
Utilization category according to IEC 60269 (EF002572) aR (accompanied semiconductor protection)
Breaking capacity (EF005617) 200 kA
Colour code (EF000931) None
Type of fuse status indicator (EF004473) Centre fuse status indicator
Power loss at rated current (EF012389) 250 W
Mounting holes (EF021553) M10
Centre-to-centre distance of connections (EF021151) 87.6 mm
Mfr: Eaton – Bussmann Electrical Division
Mounting Type: Requires Holder
Fuse Type: Square
Current Rating (Amps): 1.5kA
Voltage Rating AC: 1 kVAC
Breaking Capacity @ Rated Voltage: 200kA
Features: Indicating
Size / Dimension: 4.724″ L x 4.134″ W x 3.724″ H (120.00mm x 105.00mm x 94.60mm)
Datasheet: 170M7636
