Description

1566 Adafruit Industries Battery Charger USB Power Bank 2A 2A for LithiumIon, Desktop USB MicroB, USB A (2)
A large-sized rechargeable battery pack for your Raspberry Pi (or Arduino, or Propeller, or anything else that uses 5V!). This pack is intended for providing a lot of power to an GPS, cell phone, tablet, etc but we found it does a really good job of powering other miniature computers and micro-controllers. If you want something a little smaller, we have a 5000mAh power pack with one USB port that can provide up to 2.1A We tested it with an iPad mini, iPad 1 & 3 and iPhone 5 & 5s so we know it will charge those models.

Inside is a massive 10,000mAh lithium ion battery, a charging circuit (you charge it via the USB cable attached), and two boost converters that provide 5VDC at 2A each via a USB A port. Either can be used for when you want to power a Beagle Bone or Raspberry Pi, wifi adapters, maybe even small displays. We hooked it up to a 2.5″ NTSC display (powered from the Pi’s 5V breakout lines), wireless keyboard/mouse and a small WiFi dongle and it hummed along just fine as a mini computing setup!

The older version of this product had 1A and 2A outputs. The current version has 2 x 2A outputs.

The charging circuit will draw 1A from a 5V supply (plug a microUSB connector into the pack and then to a computer or wall adapter). You can charge and power something at the same time but the output switches to the USB input when charging so the output voltage may fluctuate. Its not good as a ‘UPS’ power supply for an embedded linux board, although microcontrollers like Arduino may not care about the voltage drop as much. Also, there’s ~80% efficiency loss on both ends so if you charge it at 1A and draw 1A at the same time, the battery pack will eventually go empty. However, if you’re powering something thats 500mA or less, you can keep it topped up no problem. Also, when you start and stop charging the pack, it will flicker the output, this can cause a ‘power sensitive’ device like the Pi or an iPhone to reset on the power supply. If using it with a low current load, say under 100mA, the pack may ‘fall asleep’ – you can use this circuit to keep the pack awake
Type: USB Power Bank
Input Voltage: 5V
Nominal Voltage:
Charge Current Max: 2A
Number of Cell: 1
Termination Style: USB MicroB, USB A (2)
Mounting Type: Desktop
