Description

0528061010 Molex 52806 FPC Connector 10 Position, 0.039″ (1.00mm) Pitch, 50V Through Hole Kinked Pin
Connector Flat Flex Type: FPC
Connector Contact Type: Contacts, Vertical – 1 Sided
Number of Position: 10
Pitch: 0.039″ (1.00mm)
Termination: Kinked Pin
FFC, FCB Thickness: 0.30mm
Height Above Board: 0.213″ (5.40mm)
Cable End Type: Straight
Contact Material: Phosphor Bronze
Contact Finish: Tin
Operating Temperature: -20°C ~ 80°C
Housing Material: Polyphenylene Sulfide (PPS)
Material Flammability Rating: UL94 V-0
Mounting Type: Through Hole
Manufacturer: Molex
Manufacturer Part #: 0528061010
